The FC Connector named as Fixed Connection Connector, which is originally developed by Seiko Instruments. It is one of the most popular connectors, because of its rugged metal housing, designed for use in unstable environments which provides a secure connection. The FC is a screw-in (thread) connector and has to be turned to make or break connection. The Fiberyo FC connector is available in both singlemode and multimode versions, and fully intermateable with NTT-FC products. Both singlemode and multimode have zirconia ferrules with pre-radiused PC profile and convex spherical end, or the 8o angle (SM) in a step or conical endface for the APC version. All our FC connectors are able to achieve low optical loss and back reflection while ensuring maximum repeatability. FC 1pc Connector and FC Connector kits are available for choices from us.
Catalogue DownloadSpecifications
Parameters | Single-mode | Multimode | |||
UPC | UPC | APC | APC | MM | |
Premium | Standard | Premium | Standard | Standard | |
Typical Insertion Loss (dB) | 0.05 | 0.08 | 0.07 | 0.12 | 0.10 |
Max Insertion Loss (dB) | 0.15 | 0.20 | 0.15 | 0.25 | 0.20 |
Typical Return Loss (dB) | ≥55 | ≥65 | ≥25 | ||
Operating Temperature (°C) | – 40 to +75 | ||||
Durability | <0.2dB typical change, 500 matings | ||||
Ferrule Ø | 125μm | 127μm | |||
*SAISO is providing Standard and Premium two levels for choices, which are better to meet your different applications and requirements.
Features
· Low insertion loss and back reflection loss
· Available with pre-assembled 1pc and connector kits for fiber connectors' assemby options
· Available with 0.9mm, 2.0mm and 3.0mm boots connectors
· Various housing/boots color for choices, SM, MM and APC
· Flammability rating: UL 94V-0; TIA/EIA, IEC and Telcordia GR-326 compliance
· Meets with RoHS and REACH
Applications
· Data Communications
· Telecommunications
· Optical Test & Laboratory Equipments
· CATV
